You may have to rotate the IPROBE from the Edit Menu (or use Ctrl R), so that the reading is in the assumed direction of current.
The reference direction of current for the circuit elements is from the first listed subscript to the second one. To obtain the DC current in a branch an IPROBE is placed in that branch. To monitor a DC node voltage a VIEWPOINT is placed at that node.
Click the Enabled check box in the Bias Load Point option. All capacitors are replaced by the pen-circuit, and all inductors are replaced by short circuits. If any AC sources are present in the circuit, those sources are set to zero. To obtain current and voltage in a DC circuit, the analysis is performed with the simple Load Bias Point.
